Description
4 x General Electric – Used Wind Turbines
GE 1.5 S Wind Turbine – For Sale – Immediately Available!
There are 4 complete units with 64m Tower, 70m Rotor Diameter incl. 30kV transformer – Available now
- Year of build: 2003
- 2 units with new gearboxes in 2005 and 2 units with new gear boxes in 2009!
- All in very good condition and currently still in operation in Europe.
GENERAL INFORMATION:
- Rated capacity: 1,500 kW
- Cut-in wind speed: 4 m/s
- Cut-out wind speed 600 s average: WZ II: 22 m/s WZ III, IEC II: 25 m/s
- Cut-out wind speed 30 s average: WZ II: 25 m/s WZ III, IEC II: 28 m/s
- Cut-out wind speed 3 s average: WZ II: 27 m/s WZ III, IEC II: 30 m/s
- Cut-back-in wind speed 300 s average:
- WZ II: 19 m/s WZ III, IEC II: 22 m/s
- Rated wind speed: 12 m/s
Rotor
- Number of rotor blades: 3
- Rotor diameter: 70.5 m
- Swept area: 3,904 m2
- Rotor speed (variable): 11.1 – 22.2 rpm
Tower
- Tower height (m): 63
Power Control
- Active blade pitch control
Operating Limits (outside temperature)
- Cold weather light: -4 to 104 °F (-20 to 40 °C)
- Cold weather extreme: -22 to 104 °F (-30 to 40 °C)/-40 °C to +50 °C survival without operation
Control System
- Programmable logic controller (PLC)
- Remote control and monitoring system
Gearbox
- Three-step planetary spur gear system
Generator
- Doubly-fed three-phase asynchronous generator
Braking System (fail-safe)
- Electro mechanical pitch control for each blade (three self-contained systems)
- Hydraulic parking brake
Yaw System
- Electro mechanical driven with wind direction sensor and automatic cable unwind.
Converter
- Pulse-width modulated IGBT frequency converter
Tower design
- Multi-coated, conical tubular steel tower with safety ladder to the nacelle
- Load lifting system, load-bearing capacity more than 441 lbs (200 kg)
- Service platform for 100 m hub height (service lift optional)
Noise Reduction
- Impact noise insulation of the gearbox and generator
- Sound reduced gearbox
- Noise reduced nacelle
- Rotor blades with minimized noise level
Lightning Protection System
- Lightning receptors installed on blade tips
- Surge protection in electrical components
PLEASE NOTE
- Inspections can be arranged by issuing a signed letter of intent.
- No time wasters, please
