Description
Urgently Seeking Spare Parts for a
NEG MICON 750 44 Wind Turbine
Please see below list and contact add owner if you have any of these parts in good condition for sale:
Technical Specifications:
Rotor – Quantity: 2 (6 blades)
Rotor NM 750/44 IEC1 + long bladetip + damping in blade
a. Blades: 3
b. Swept area 1520 m2
c. Synchronic rotor speed 27/18 rpm
d. Tip speed 62.1 m/s
e. Inclination of the rotor axis 5°
f. Tip angle -1.7°
g. Wind orientation upwind
h. Complete rotor with extenders
Main Panel AT1 – Quantity 1 :
b. Main Panel AT1 600 V
c. 60 Hz
d. Tropic
e. Dan Control
f. 750 kW
g. 3 x 600 V
h. Maximun cut-in G2 450 A
i. Maximun cut-in G1 730 A
j. Cut-in system soft with trystors
k. Maximun power 840 kW
Computer panel – Quantity: 1
a. Computer Panel AT2
b. 600 V 60 Hz Tropic
c. TAC/TOI Computer Panel DanControl
Power cables (for wind turbine) – Quantity 250 m
I. Power cable
II. 2/0 AWG-4C
III. 600 a 2000V 90ºC
IV. Similar to E207132C FT1FT5L-40CL P-7K
Multiline control cable – Quantity: 60 m
I. Control cable 37 x 18 AWG
II. 600 V
Multiline control cable – Quantity: 110 m
I. Control cable 30 x 14 AWG
II. 600 V
Multi line control cable, Quantity: 65 m:
I. Control cable 3 x 14 AWG
II. 600 V
Cable de control Multilínea – Quantity: 40 m
I. Cable de control 3 x 12 AWG
II. 600 V
